LED dot size

3mm

LED color

Red

Dot pitch

4.6 mm

Dot matrix

5 dots (W) x 7 dots (H)

Material

Main rack & keel are aluminum, front &backsides are metal.

Resolution

120 (W) dots x 7 (H) dots per line

Display area

55.2 cm (W) x3.22 cm(H) x 7 lines/ 55.2 cm (W) x3.22 cm(H) x 8 lines

Cabinet size

680 mm (W) x1860 mm(H) x150 mm(D)

Maximum characters

20 characters per line (for 5 x 7 dots character font) total 7/ 8 lines per set

Viewing distance

20M Max.

Power consumption

Normally 80W, Max. 250W

Power input

AC 110V/ 230V

Control way

By IR/ 55 keys

By RS-232 built in windows software attached. (Optional)

Illuminated logo  (Optional)
