Specification:

Display size (Display area)

281.6 cm (W) x  88 cm (H)

Display resolution

128 dots (W) x 40 dots (H)　

LED per dot

2 Red, 1 Pure Green, 1 Blue

Dot size

22 mm

Dot pitch　

22 mm

Colors

281 trillion

Grade of each color ( R.G.B.)

1024/ 2048/ 4096/ 8192 / 16384/ 32768/ 65536 ( 16 bits) optional

Luminosity Maximum

+5,000 cd / M²

LED angle

110°(H) ,  40°(V)

Special features

Gamma Correction

Dimmer control

256 level

Frame rate

60Hz±10Hz

Operating temperature

-10℃ ~ + 50℃

Storage temperature　

-25℃ ~ + 85℃

Power consumption

2000W (Max) 128x 40 dots
